In the realm of deep learning, Convolutional Neural Networks (CNNs) have significantly transformed the approach to image processing and recognition tasks. Specifically designed for grid-like data such as images, CNNs excel at extracting spatial hierarchies of features. This capability allows them to identify patterns, shapes, textures, and objects from raw pixel values, making CNNs a fundamental model for applications such as image classification, object detection, and segmentation.

Unlike traditional Multi-Layer Perceptrons (MLPs), CNNs utilize a more specialized architecture by employing filters—learnable, 2-dimensional matrices that slide across images to perform convolution operations. These filters are trained to detect specific patterns, including edges and textures, by analyzing local patches of an image.

The necessity of CNNs arises from their efficiency in handling high-dimensional data like images. Traditionally, feature extraction involved manual methods, which tended to be both time-consuming and ineffective. In contrast, CNNs automate this process to learn the most relevant features directly from the data, thus becoming the backbone of modern computer vision applications, from self-driving vehicles to facial recognition technology.

This article delves into the role of filters within CNNs, examining their interaction with images across various network layers. A deeper understanding of these learnable parameters reveals how CNNs process complex image datasets and make informed predictions.

Prerequisites

To follow along with this tutorial, a basic understanding of Python programming and neural networks is essential. The discussion is aimed at intermediate to advanced coders who are familiar with developing novel architectures. The code provided can be run on a typical home PC or a DigitalOcean Droplet.

Neural Nets and Feature Extraction

An essential function of neural networks is to extract features from data, which aids in achieving tasks like classification and regression. While this process is straightforward in MLPs, it becomes more complex in CNNs due to their handling of two-dimensional data from images, rather than a vector of attributes.

For instance, consider an enhanced image of a cat, which consists of 640 columns and 480 rows of pixels—resulting in a total of 307,200 attributes. The key question arises: what constitutes a feature in regards to images?

Images On Edge

Much of the important information in an image is preserved in its edges, which is why our brains can easily recognize shapes and objects. Studies suggest that edge perception is one of the earliest processes involved when we view images, a technique also utilized by birds when navigating and landing.

CNNs and Human Vision

There is considerable discourse around how neural networks mimic human cognitive processes. Just as the human brain focuses on edges when processing visual information, CNNs initiate the feature extraction process by detecting these edges. The filters within CNNs serve to extract these features, with early layers focusing on low-level features like edges, while deeper layers concentrate on higher-level features.

Filtering Out Edges

CNNs can learn specialized edge detection filters that correspond to patterns from the dataset they are trained on. These filters, although learned, can be based on established manual edge detection techniques such as Prewitt, Sobel, Laplacian, Robinson Compass, and Krisch Compass filters.

An example function to perform convolution using these filters can be illustrated as follows:

import numpy as npimport torchimport cv2import matplotlib.pyplot as pltdef convolve(image_filepath, filter, title=''):    # Load image in grayscale    image = cv2.imread(image_filepath, cv2.IMREAD_GRAYSCALE)    filter_size = filter.shape[0]        # Create an array for convolutions    convolved = np.zeros((image.shape[0] - filter_size + 1, image.shape[1] - filter_size + 1))        # Perform convolution    for i in range(image.shape[0] - filter_size + 1):        for j in range(image.shape[1] - filter_size + 1):            convolved[i, j] = (image[i:i+filter_size, j:j+filter_size] * filter).sum()        # Convert to tensor and apply ReLU activation    convolved_tensor = torch.tensor(convolved)    convolved_tensor = torch.nn.functional.relu(convolved_tensor)    # Producing plots    figure, axes = plt.subplots(1, 2)    axes[0].imshow(image, cmap='gray')    axes[0].set_title('Original')    axes[1].imshow(convolved_tensor.numpy(), cmap='gray')    axes[1].set_title('Convolved')

Conclusion

This article discussed how filters function in Convolutional Neural Networks, particularly focusing on edge detection and feature extraction. CNNs are effective not only because they base their functionality on fixed filters but because they learn optimal filters during training to capture features specific to the dataset. This offers a considerable advantage and flexibility over traditional methods, enabling accelerated learning and enhanced performance in complex image processing tasks.
