CSF Firewall Rules: What Every Hosting Provider Should Know

ConfigServer Security & Firewall (CSF) is a popular and feature-rich firewall solution for cPanel servers. It adds an extra layer of security by integrating seamlessly with iptables, providing robust features like brute-force protection, IP whitelisting/blacklisting, and detailed logging.

In this guide, we’ll walk you through configuring CSF on a cPanel server, along with key firewall rules that every hosting provider should know to enhance server security and performance.

Step-by-Step Guide to Configuring CSF on a cPanel Server

Follow these steps to install and configure CSF on your cPanel server:

Step 1: Install CSF

Before starting, ensure that your server meets the requirements for CSF installation.

• Log in to your server via SSH as the root user.
• Run the following commands to download and install CSF:

cd /usr/src
wget https://download.configserver.com/csf.tgz
tar -xzf csf.tgz
cd csf
sh install.sh


• Once installed, CSF can be managed via WHM or command-line tools.

Step 2: Verify CSF Installation

After installation, verify that CSF is working correctly:

• Run the following command to check the status:

csf -v


• If the version number appears, the installation was successful.

Step 3: Disable Testing Mode

CSF starts in testing mode by default to prevent accidental lockouts. Disable it to activate CSF:

• Edit the CSF configuration file:

nano /etc/csf/csf.conf


• Find the line TESTING = "1" and change it to:

TESTING = "0"


• Save the file and restart CSF:

csf -r


Step 4: Configure Basic Firewall Rules

CSF provides default rules that work for most cPanel servers. However, you may need to customize them based on your hosting environment.

• Edit the CSF configuration file:

nano /etc/csf/csf.conf


• Modify the following settings:
• TCP_IN: Open ports required for incoming connections (e.g., HTTP, HTTPS, SSH).

TCP_IN = "20,21,22,25,53,80,110,143,443,465,587,993,995"


• TCP_OUT: Open ports required for outgoing connections (e.g., DNS, external APIs).

TCP_OUT = "20,21,22,25,53,80,110,113,443"


• ICMP_IN: Enable or disable ping requests.

ICMP_IN = "1"


• Restart CSF to apply changes:

csf -r


Step 5: Configure IP Whitelisting and Blacklisting

To prevent unauthorized access or block malicious traffic, use CSF’s whitelist and blacklist features:

• Whitelist a trusted IP address:

csf -a


• Blacklist a malicious IP address:

csf -d


• View the current whitelist and blacklist:

csf -g


Step 6: Enable Login Failure Detection (LFD)

LFD is an integral part of CSF that detects brute-force attacks and automatically blocks offending IPs.

• Edit the LFD configuration file:

nano /etc/csf/csf.conf


• Set the following parameters:
• LF_TRIGGER: Number of login failures before blocking an IP.

LF_TRIGGER = "5"


• LF_BLOCK: Enable blocking of IPs after failed login attempts.

LF_BLOCK = "1"


• Restart CSF and LFD:

csf -r
service lfd restart


Essential CSF Firewall Rules Every Hosting Provider Should Know

To ensure optimal server security, implement these key rules:

1. Set Default Deny Policies

Deny all incoming and outgoing traffic by default, then explicitly allow only the necessary ports and IPs.

DEFAULT_INPUT_POLICY = "DROP"
DEFAULT_OUTPUT_POLICY = "DROP"


2. Rate-Limit Connections

Prevent DDoS attacks by limiting the number of connections from a single IP address.

CONNLIMIT = "80;20,443;20"


This limits HTTP and HTTPS connections to 20 per IP.

3. Enable Port-Specific Alerts

Receive email notifications when specific ports are accessed:

PORTFLOOD = "22;tcp;5;300"


This triggers an alert if SSH is accessed more than 5 times within 300 seconds.

4. Protect Against SYN Floods

SYN floods are a common form of DDoS attack. Enable protection in the CSF configuration:

SYNFLOOD = "1"
SYNFLOOD_RATE = "100/s"
SYNFLOOD_BURST = "150"


5. Log and Monitor Traffic

Keep track of all traffic for auditing purposes. Enable detailed logging in CSF:

LOGGING = "1"


Conclusion

CSF Firewall is a powerful tool for securing cPanel servers, offering features like IP whitelisting, rate limiting, and login failure detection. By following this step-by-step guide and implementing essential rules, hosting providers can enhance their server security and protect against a wide range of threats.

Take the time to customize CSF for your specific needs, regularly review logs, and test your configurations to ensure optimal performance. A properly configured CSF setup is your first line of defense against malicious traffic and unauthorized access.
